Used HARTFORD PBM-135B Horizontal Milling

Used HARTFORD PBM-135B Horizontal Milling

Contact us for price

Location:Singapore

or
Call +65 68425655

Description

Standard-Mechanical

  • B-axis 0.001 degree
  • RS-232
  • Spindle oil cooler
  • Tool arm type (40 tools)
  • 2500 RPM gear type spindle
  • Air blast through spindle
  • MPG
  • Lubrication system
  • Convection heat exchanger in control box
  • XYZ axis linear scale system (Fagor)
  • B axis linear scale system (Heidenhain)
  • Mist coolant system
  • Table side air blast


Machine sold at “as it, where is” condition.

All information regarding machine tool specification is correct to the best of our ability and knowledge, but we cannot guarantee 100% accuracy. Please clarify & inspect the machine before committing to a sale.

Show All

Specifications

ManufacturerHARTFORD
ModelPBM-135B
Year2011
ConditionUsed
Stock Number8573323
Table Size1600 x 1800mm
Table Load Capacity12,000 Kg
X/Y/Z Axis Travel2500 / 2000 / 1500mm
W Axis Travel700mm
Max Spindle Speed2500 RPM
Spindle TaperBT50
ATC60 Tools
Machine Dimension7370 x 8650 x 4744mm
Machine Weight (Approx)32,000 Kg
